Stations Rotation
Newton's Laws Lab Stations
50 min30 students10th GradeBloom’s Level: Remember, Understand, Apply, Analyze
Before Class
Materials Needed
- ☐Index cards
- ☐Pennies
- ☐Glass beakers or plastic cups
- ☐Dynamics carts
- ☐Spring scales
- ☐Set of weights (500g, 1kg)
- ☐Balloons
- ☐Straws
- ☐String
- ☐Tape
- ☐Stopwatches
Space Needed
Tables/desks arranged in 4-6 distinct stations around room
Topic Overview
Exploring the tendency of objects to resist changes in motion and the concept of equilibrium.
Key Questions
- ?How does inertia explain why headrests are necessary in cars?
- ?What is the difference between mass and weight in a zero-gravity environment?
- ?How do satellites maintain their motion without constant propulsion?
About the Methodology
The classroom is divided into 4-6 stations, each with a different activity related to the topic (e.g., source analysis, map work, timeline construction, creative response, discussion prompt). Groups rotate through all stations on a timed schedule. Provides variety and movement within a single class period.
Learn about this methodologyTime Range
35-55 min
Group Size
15-36
Space Needed
Tables/desks arranged in 4-6 distinct stations around room
Bloom’s Level
Remember, Understand, Apply, Analyze
Fun Factor
Peak Energy Moment
The 'Penny Drop' creates an immediate 'magic trick' feel that engages even the most skeptical students.
The Surprise
Students are often shocked at how difficult it is to keep a spring scale steady at exactly 1 Newton while a cart is moving.
What to Expect
High energy during the balloon launches, followed by focused curiosity during the collision station.
Mission Timeline
5m
7m
32m
6m
Spark Briefing Action Debrief
Academic Standards
STD.HS-PS2-1CCSS.HS-RST.9-10.3
Spark
5 min • Scenario
Read Aloud
Imagine you are standing on a skateboard holding a heavy 10kg medicine ball. You throw the ball forward as hard as you can. Even though you threw the ball away from you, you find yourself rolling backward at a significant speed. Why did you move if you weren't the one being thrown?
Teacher Notes
Use this to prime their brains for action-reaction pairs. Do not give the answer yet; tell them they will find the physical proof at Station 3.
Briefing
7 min
Today you will rotate through four stations to gather evidence for Newton's Laws. Each station has a specific procedure and a set of safety rules. You must record your data immediately on your lab sheet. You will have 8 minutes per station. When the buzzer sounds, clean your area and move clockwise to the next number.
Group Formation
Divide the class into 8 groups of 3-4 students. Two groups will start at each station (A and B setups for each) to keep groups small.
Materials Needed
- •Index cards
- •Pennies
- •Glass beakers or plastic cups
- •Dynamics carts
- •Spring scales
- •Set of weights (500g, 1kg)
- •Balloons
- •Straws
- •String
- •Tape
- •Stopwatches
Action
32 min • 100% Physical
18 min
Station 1 (Inertia): Students perform the 'Penny Drop' by flicking an index card out from under a penny resting on a beaker.
Check that students are flicking the card horizontally, not upward.
28 min
Station 2 (F=ma): Students pull a cart with a constant force using a spring scale, first empty, then loaded with weights.
Remind students to keep the spring scale reading constant during the pull.
38 min
Station 3 (Action/Reaction): Students set up balloon rockets on strings and measure how far the 'exhaust' pushes the balloon.
Ensure the string is taut to minimize friction interference.
48 min
Station 4 (Synthesis): Students predict and test what happens when a moving cart (Law 1) hits a stationary cart (Law 3) with different masses (Law 2).
Encourage students to use the vocabulary from the first three stations here.
If things go sideways
- ▸If a group is struggling with the spring scale at Station 2, demonstrate how to walk backward at a steady pace to maintain a 1-Newton force.
- ▸If the balloon rocket is stuck, check for tape friction against the straw or a sagging string.
- ▸For students confused by the penny drop, ask them to describe the penny's motion in slow motion to identify the 'lack' of horizontal force.
Differentiation Tips
- ▸Advanced: At Station 2, have students calculate the theoretical acceleration using a=F/m after weighing the cart.
- ▸Struggling: Provide a visual 'Force Arrow' diagram at Station 3 to show the direction of air vs. the direction of the balloon.
- ▸ELL: Use the structured 'Observation/Inference' table on the lab sheet with sentence starters like 'I saw...' and 'This happened because...'
Debrief
6 min
Discussion Questions
- 1
At Station 1, why didn't the penny move sideways with the card?
- 2
Based on Station 2, if you double the mass but keep the force the same, what happens to the acceleration?
- 3
In the balloon rocket, identify the two objects involved in the action-reaction pair.
Exit Ticket
A soccer ball sits on the grass until a player kicks it. Which of Newton's three laws are demonstrated in this moment? Explain one.
Connection to Next Lesson
Now that we have seen these laws in isolation, tomorrow we will use them to calculate the exact forces needed to land a probe on Mars.
